Monday, August 9, 2021

CELL BIOLOGY- 3

 CYTOLOGICAL TECHNIQUES



The processes that are implemented to observe cells and their components are said to be cytological techniques. There are 5 basic methods via which cytological specimens are studied:

  1. Teasing
  2. Smear preparation
  3. Squash preparation
  4. Whole mounting
  5. Microtomy

Teasing: Most of the musculature is observed by teasing with saline solution. A Safranin or Eosin stained specimen is viewed under microscope.

Smear preparation: It is a film of a fluid tissue which is dried, stained, covered with a cover glass and observed under the desired model of microscope.


smear of different samples

Squash preparation: Soft tissues such as onion root tip, testes are prepared by softly pressurizing them into soft thin layers within cover glasses.

squash of onion root tip cell


Whole mounting: The process of mounting a specimen as such without any of the above mentioned preparatory processes is said to be whole mounting.


Microtomy:  It is the mechanism of producing thin, transparent sections of cells, tissues which are further subjected to temporary or permanent microscopic studies. Detailed studies on microscopic specimen can be made on cells and tissue samples which undergo a series of physical and chemical treatments. The treatments are listed as follows:

  • Fixation
  • Dehydration
  • Clearing
  • Embedding
  • Sectioning
  • Staining
  • Mounting
  • Labelling

Let us unravel each of the above mentioned treatments in the fore-coming blogs.
Until then stay tuned.

Sunday, August 8, 2021

CELL BIOLOGY -2

 BIOMOLECULES AND THE CELL


90%   of  living  matter  made  of  C,H,O,N,S,P  AND  10%  is composed of C,H,O,N,S,P & 10%  is composed  of  K , Ca , Na ,Mg , Cl , F, I , Fe , Zn , Mo , Se , Cu , Co.

Among  these   carbon  plays  a  very  important  role because  of  its  tetravalency,  isomerism  and  covalent bond  forming  capacity.

E.coli has 6000 types  of  organic compounds and  a  human  cell  has 1 lakh types of  organic molecule.

MICROMOLECULE

MACROMOLECULE

FUNCTIONS

PROTEINS

AMINO ACIDS

BASIS OF STRUCTURE AND FUNCTION(STATIC AND DYNAMIC).

DNA

DEOXYRIBONUCLEOTIDES

REPOSITORY OF GENETIC INFORMATION

RNA

RIBONUCLEOTIDES

PROTEIN BIOSYNTHESIS

POLYSACCHARIDES

MONOSACCHAARIDES

SHORT TERM ENERGY

LIPIDS

FATTY ACIDS AND  GLYCEROL

LONG TERM ENERGY


Simple   inorganic   molecules  form  bio micromolecules. The   latter  form  biomacromolecules. These  inturn  form   supra-molecular  assemblies,  which  are  required  to  form the cell organelles , their membranes  and  the  cytosol.

All  the organelles  form a cell. Cells  aggregate  to form tissues. These  then  form  organs .Organs  form  organ  systems  which  coordinate  to  regulate  the  organism.

For  a 65 kg man, the body is comprised of  the  following:

40 kg

60%

Water

11 kg

17%

Proteins

9 kg

13.8%

Lipids

1 kg

1.5%

Carbohydrates

6.1 kg

4%

Minerals.


Cell   is  the  structural  and  functional  unit  of  life. The  organelles  of  a   cell  can  be  easily  isolated  by  differential  centrifugation.

Prokaryotic cell

Eukaryotic cell

1 to 10 micron.

10 to 100 micron.

Well defined nucleus absent

Well defined nucleus present.

Nuclear envelope absent

Nuclear envelope present

Most cell organelles  absent

All  cell  organelles  present.

Primitive

Advanced


















Cell  organelles :-



       A. Nucleus:-

§  Largest  cell  organelle.

§  Double  membrane  envelope.

§  Outer  memrane  is  connected  with  e.r.

§  Nuclear  pores  (diameter= 900 nm.)

§  DNA– repository  of  genetic  information.

§  RNA-  protein biosynthesis.

§  Eukaryotic  dna :  histone  proteins =  1:1.

§  DNA+ histones  = nucleosomes.

§  1  chromosome  has  millions  of  nucleosomes.

§  46  chromosomes  in  human  genome.

§  Nucleus  has  nucleolus  rich  in  RNA.

§  Nucleoplasm  is  rich  in  enzymes  like  DNA polymerases  and  RNApolymerases.


B. Mitochondria:-

§  Mitos- thread ,  chondrus – granule.

§  Power  house  of  cell.

§  Various  shapes  andv sizes.(dimension =  1 × 3 μm).

§  Double  membrane  system.

§  1- 5 th  of cell  volume  covered  by  2000 mitochondria.

§  Outer  membrane – soft  and  continuous.

§  Inner  membrane   -  cristae  formation.

§  Matrix  of  mitochondria  is  called  mitosol.  It  has  chemicals  like  flavoproteins, cytochromes b, c1, c, a, a3 .(useful  in  electron  oxidation chain  and  oxidative  phosphorylation.)

§  Reactions  like  biomolecule  metabolism,  beta  oxidation ,  citric  acid   cycle, ATP production,  heme  and  urea  synthesis  occurs  in  matrix.

§  The  inner  membrane  contains  coupling  factors.

            §  Mitochondria  has  its  own  DNA, RNA,  proteins.

§  It prepares  its  own  proteins(10% of  total  cell  protein).

§  Aerobic  prokaryotes  evolved  into  mitochondria  which  then  lived  with  symbiosis  with  anaerobic  eukaryotes  . These  later  evolved  into  aerobic  eukaryotes.


C. Endoplasmic  Reticulum:-

§  Smooth endoplasmic reticulum (S.E.R)

                -    calcium ion supply.

          -     drug  metabolism.

           -  lipid  synthesis.  (triacylglycerol, phospolipids, sterols .)

§ Rough endoplasmic reticulum(R.E.R) -  granular  in appearance.

{R.E.R – associated with the factories of protein biosynthesis(ribosomes).}

 E.R – disrupts to form microsomes during cell fractioning.


  D. Golgi  apparatus :-

  • Dictyosomes(unique cluster of membrane vescicles)  modify  to form  golgi complex.
  • It  modifies  protein  by  adding  carbohydrates , lipids or sulphate  moeities  to  the  polypeptide  chain.
  • Involved  in  membrane  synthesis  of  organelles  like peroxisomes  and  lysosomes.

        E. Lysosomes :-

  • Single  membrane.
  • Digestive   tract  of  cell.
  • It’s  enzymes -  hydrolases –  α- glucosidases,  cathepsins , lipases , ribonucleases.
  • These  maintain  the  dynamics  of  cellular  components.
  • Lipofuscin  -  wear  and  tear  pigment  or  age  pigment  accumulate  in  cell .  Cells  rich  in   lipofuscin  need to  be  destroyed  by the  post- mortem  autolysis.

       F. Peroxisomes:-

§ Also  called  microbodies.

§ Single  membrane.

§ Oval  to  round.

§ Contain  enzyme  catalase -  breakes  hydrogen  peroxide  into  water  and oxygen.

§ Also  oxidises  long  chain  fatty  acids.

§ Synthesizes  plasmalogens  and  glycolipids.

§ In  plants , called  glyoxisomes  - do  glyoxylate  pathway.

§ Peroxisome  biogenesis  disorders  have  high   amount  of  c-24  to  c-26  and  less  plasmalogens.

§ Its  sincere  case  is  zellweger  syndrome  -  death within  one  yr  after  birth.(absence  of  functional  peroxisomes).


G. Cytosol  and  cytoskeleton:-

§             Cytosol  = cell  matrix  -  it  has  enzymes,  metabolites,  electrolytes  in  aqueous.

§             Cytoskeleton = complex  network  of  protein  filaments

§             It   has  microtubules  ,  actin  filaments,  intermediate  filaments.










Saturday, August 7, 2021

CELL BIOLOGY - 1

Cell biology on and before the classic era.

Cell biology is the study of the structure and functions of the cells.It is also known as cytology.It started as an independent branch of biology in 1893, when Hertwig made a clear distinction between cytology and histology. Schwann is known as the father of cell biology as he was the foremost to elaborate on the morphology and physiology of  the cell for the first time.

History of cell biology before 19th century.


YEAR

NAME

CONTRIBUTION

1658

Jan Swammer Dam

1st observed red blood cells in frogs

1665

Robert Hooke

Observed dead cells with cell walls in Quercus (Spanish Oak) bark

1723

Leeuwenhoek

Studied spermatozoa, protozoa,etc., under self constructed microscopes




History of cell biology in 19th century.

In the 19th century(1800-1900), considerable discoveries were made in cytology. This period is described as the Classical period. During this period, almost all the cell organelle were discovered. The 19th century witnessed the folllowing major milestones in the field of cytology:
  • Formulation of cell theory
  • Formulation of protoplasm theory
  • Discovery of cell division
  • Discovery of nucleus
  • Discovery of protoplasm
  • Discovery of chromosomes
  • Discovery of plastids
  • Discovery of Golgi apparatus
  • Discovery of spindle fibres
  • Discovery of nucleic acids
  • Discovery of centriole
  • Discovery of giant chromosomes
  • Discovery of the role of nucleus in heridity
  • Discovery of ergastoplasm
  • Discovery of mitochondria
  • Proposal of germ plasm theory

CYTOLOGY IN THE  CLASSIC ERA

YEAR

NAME

CONTRIBUTION

1808

MIRABEL

Stated that plants have membranous cellular tissues

1824

DUTROCHET

Stated that all plants and animals are made of cells

1824

PREVOST & DUMAS

Described cell division by studying cleavage in frog’s egg

1826

TURPIN

Reported occurrence of cell division

1828

BROWN

Described Brownian motion in cytoplasm

1830

AMICI

Described fertilization in plants

1831

ROBERT BROWN

Reported nucleus in plant cells

1832

DUMORTIER

Studied cell division in algae

1835

FELIX DUJARDIN

Described protoplasm as “sarcode”

1835

VON MOHL

Described cell division in animals

1838

SCHLEIDEN

Described nucleolus and formulated cell theory

1839

SCHWANN

Applied cell theory to animals

1840

PURKINJE

Named the cell contents as protoplasm

1845

DONNE

Studied spermatozoa under photomicroscopy for the 1st time

1846

HUGO VON MOHL

Used the term “protoplasm”

1848

HOFMEISTER

Drew chromosome of pollen of Transcendentia and described nuclear divisions in stamen

1855

VIRCHOW

Stated that all cells arise from pre-existing cells

1861

SCHULIZE

Proposed “protoplasm theory”

1863

WALDEYER

Used haematoxylin stains for tissues and described chromosome structure

1866

HAECKEL

Named “plastids”

1867

George

Observed golgi apparatus

1870

His

Developed microtomy

1870

Fol

Described spindle and astral rays

1871

Miescher

Isolated nucleoproteins and nucleic acids from the pus cells

1876

Hertwig

Studied fertilization in sea urchins

1876

Hertwig

Studied fertilization in animals

1876

Pasteur

Discovered anaerobic release of energy from yeast and mold cells

1877

Abbe

Discovered oil immersion objective

1879

Fol

Observed fusion of sperm and ovum

1879

Flemming

Described chromosome splitting and discovered the term ”chromatin”

1881

Balbiani

Described giant salivary gland chromosomes during cell division

1882

Flemming

Described mitosis in animal cells and correlated nucleic acids and chromatin

1882

Pfitzner

Discovered chromomeres in chromosomes

1882

Strasburger

Discovered plant cell division, introduced the terms, “cytoplasm” & “nucleoplasm”

1883

Roux

Proposed that chromosomes contain hereditary units

1883

Van Benden

Demonstrated the reduction of chromosome count by half during gamete formation

1883

Metchnikoff

Observed and named phagocytosis in cells

1885

Hertwig & Strasburger

Proposed the role of nucleus in heredity

1886

Altmann

Studied mitochondria and their role in respiration

1886

MacMunn

Discovered cytochromes

1887

Van Benden

Discovered centriole

1888

Boveri

Described centriole

1888

Waldeyen

Introduced the term “chromosome”

1892

Weismann

Proposed “germplasm theory”

1892

Boveri

Described spermatogenesis and oogenesis in Ascaris

1897

Grainer

Named and described “ergastoplasm”

1897

Altmann & Benda

Observed the mitochondrion

`1898

Benda

Introduced the term “mitochondrion”

1898

Golgi

Described golgi complex in nerve cells of owl



Let us drench in the rich history of cytology after the classic era in our future post. Until then please stay tuned.
